F‑237543.02.SKL RICH 50x100x20

The RICH F‑237543.02.SKL single row angular‑contact ball bearing, sized 50 x 100 x 20 mm, features a polyamide cage and an open design. It offers stable support for combined loads and is interchangeable with KOYO AC10102 8009606.

RICH
F‑237543.02.SKL
€29.96
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

F‑237543.02.SKL RICH | Single Row Angular‑Contact Ball Bearing – 50 x 100 x 20 mm

OE / Interchange:

  • AC1010-2 80-09-606 KOYO

Technical Specifications:

  • Catalog Code: F‑237543.02.SKL RICH
  • Brand: RICH
  • Type: Single row angular‑contact ball bearing
  • Bore Diameter (d): 50 mm
  • Outer Diameter (D): 100 mm
  • Total Width (B): 20 mm
  • Outer Ring Width (C): 14 mm
  • Inner Ring Width: 16 mm
  • Cage: Polyamide
  • Sealing: None (open)
  • Weight: 0.547 kg
  • Country of Origin: China

Key Performance Advantages:

  • Angular‑contact geometry designed for stable support of combined loads.
  • Polyamide cage ensuring smooth ball guidance and reduced friction.
  • Open configuration suitable for applications with external lubrication.

Transparency Note: This bearing is manufactured under the RICH brand. The code F‑237543.02.SKL and the interchange references listed are used solely for identification and do not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
50
Outer Diameter
100
Width
20
Weight
0,547
Cage
Polyamide Cage
Category
Single Row Angular-Contact Ball Bearing
