CS203-2RS RICH 17x40x12

CS203-2RS RICH is a sealed insert ball bearing with cylindrical bore and rounded outer ring. Dimensions 17 x 40 x 12 mm. Origin: China.

RICH
CS203-2RS
€1.11
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

CS203-2RS RICH | Insert Ball Bearing – 17 x 40 x 12 mm

Technical Specifications:

  • Catalog Code: CS203-2RS RICH
  • Brand: RICH
  • Type: Insert Ball Bearing
  • Bore Type: Cylindrical
  • Inner Diameter: 17 mm
  • Outer Diameter: 40 mm
  • Total Width: 12 mm
  • Outer Ring Width (C): 12 mm
  • Rounded Outer Ring: Yes
  • Sealing: Double-sided rubber, contact type
  • Overall Dimensions: 17 x 40 x 12 mm
  • Weight: 0.063 kg
  • Country of Origin: China

Key Performance Advantages:

  • Contact Rubber Seals: Provide effective protection against dust, moisture, and contaminants.
  • Rounded Outer Ring: Facilitates smooth mounting in curved housing seats.
  • Compact Format: Ideal for light-duty applications and limited-space environments.

Transparency Note: This bearing is manufactured under the RICH brand. The code CS203-2RS is used solely for identification and does not imply affiliation with any other brand. The product is clearly marked with its actual brand and origin.

Data sheet

Inner Diameter
17
Outer Diameter
40
Width
12
Weight
0,063
Sealing
Lip Seal On Both Sides
Category
Insert Ball Bearing
