TM 205 RS N C3 RICH 25x52x15 TM205NC3UR RICH
TM 205 RS N C3 RICH 25x52x15 TM205NC3UR RICH
zoom_out_map
TM 205 RS N C3 RICH 25x52x15 TM205NC3UR RICH
TM 205 RS N C3 RICH 25x52x15 TM205NC3UR RICH

TM 205 RS N C3 RICH 25x52x15

The RICH TM 205 RS N C3 deep groove ball bearing, sized 25 x 52 x 15 mm, features a single‑side RS seal, snap ring groove and C3 clearance. Interchangeable with Suzuki 09262‑25129, it ensures smooth rotation and reliable performance.

RICH
TM205NC3UR
€8.22
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

TM 205 RS N C3 RICH | Single Row Deep Groove Ball Bearing – 25 x 52 x 15 mm

OE Reference:

  • 09262‑25129 SUZUKI

Technical Specifications:

  • Catalog Code: TM 205 RS N C3 RICH
  • Brand: RICH
  • Type: Single row deep groove ball bearing
  • Bore Diameter (d): 25 mm
  • Outer Diameter (D): 52 mm
  • Total Width (B): 15 mm
  • Sealing: RS – single‑side rubber seal
  • Outer Ring Groove: Yes (N – snap ring groove)
  • Internal Clearance: C3 – greater than normal
  • Weight: 0.14 kg
  • Country of Origin: China

Key Performance Advantages:

  • C3 internal clearance ideal for higher speeds and thermal expansion.
  • RS sealing providing effective protection against contaminants on one side.
  • Snap ring groove enabling secure axial positioning in the housing.
  • Deep groove geometry ensuring smooth rotation and stable load distribution.

Transparency Note: This bearing is manufactured under the RICH brand. The code TM 205 RS N C3 and the OE reference listed are used solely for identification and do not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
25
Outer Diameter
52
Width
15
Weight
0,14
Ball Rows
Single Row
Sealing
Contact Seal On One Side
Clearance
C3 (Greater than Normal)
Category
Single Row Deep Groove Ball Bearing
