NF307 RICH 35x80x21

NF307 RICH – Single Row Cylindrical Roller Bearing – 35 x 80 x 21 mm

Technical Specifications:

• Type: Single row cylindrical roller bearing (NF Design)
• Brand: RICH
• Model Designation: NF307
• Inner Diameter (d): 35 mm
• Outer Diameter (D): 80 mm
• Width (B): 21 mm
• Internal Clearance: CN (Normal clearance)
• Cage Material: Steel
• Material: High-grade bearing steel
• Weight: 0.508 kg
• Country of Origin: China

Performance Characteristics:

• NF Design Profile: Configured with two integral ribs on the inner ring and one integral rib on the outer ring, allowing for axial displacement of the shaft in one direction.
• Load Management: Engineered to support high radial loads while maintaining low friction levels during high-speed rotation.
• Structural Integrity: Features a precision-pressed steel cage that ensures uniform roller spacing and effective lubricant distribution across the raceways.
• Mechanical Precision: Manufactured with CN normal internal clearance for standard industrial applications where thermal expansion is within regular operating limits.

Transparency Note:

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
