110-XL-24 RICH XL Timing Belt - L=279.4 mm, W=24 mm
Technical Specifications:
- Brand: RICH
- Type: Timing Belt
- Model: 110-XL-24
- Profile: XL
- Pitch (t): 5.08 mm
- Pitch Length (Ld=Lp=Lw): 279.4 mm
- Number of Teeth: 55
- Width (W): 24 mm (Inferred from Model)
- Belt Thickness (hs): 2.3 mm
- Tooth Height (ht): 1.27 mm
- Weight: 0.014 kg
- Country of Origin: China
The 110-XL-24 RICH is a robust XL Timing Belt produced by RICH, specifically designed for applications requiring enhanced power transfer capability and stability within the XL profile. This belt features a pitch length of 279.4 mm with a standard XL pitch of 5.08 mm, giving it a total of 55 teeth. The 24 mm width provides a substantial increase in torque capacity and lateral stability compared to narrower XL belts, making it suitable for demanding light-duty industrial drives.
Constructed from highly durable materials and internally reinforced with high-strength tensile cords, the 110-XL-24 RICH ensures minimal stretch and maintains precise dimensional accuracy over its service life. The trapezoidal XL tooth form guarantees positive, non-slip engagement with mating pulleys, making it an excellent choice for a variety of industrial equipment, automated assembly lines, and high-precision conveying systems.
Key Performance Advantages:
- Synchronous Drive: Provides positive, non-slip power transmission for accurate positioning and timing.
- Wider 24 mm Construction: Offers superior stability and increased power handling for an XL belt.
- XL Profile: Standard trapezoidal tooth form for reliable compatibility and operation.
- Dimensional Stability: Reinforced cords ensure consistent length and minimal elongation under load.
