F-227653 RICH 30x46,5x27

F-227653 RICH – Single Row Cylindrical Roller Bearing without Outer Ring – 30 x 46.5 x 27 mm

OE References:

• CATERPILLAR: 1550838 | 155-0838
• ZF: 0735455295

Technical Specifications:

• Type: Single row cylindrical roller bearing without outer ring (Inner ring and roller assembly)
• Brand: RICH
• Model Designation: F-227653
• Inner Diameter (d): 30 mm
• Outer Diameter (D) - Roller Assembly: 46.5 mm
• Width (B): 27 mm
• Cage Material: None (Full complement)
• Sealing: Open
• Weight: 0.176 kg
• Country of Origin: China

Product Details:

• Components: Consists of a heavy-duty inner ring with integral retaining flanges and a full complement single row of high-precision cylindrical rollers, designed to operate without a separate outer ring.
• Internal Geometry: Engineered as a cageless, full complement layout where the precision rollers run directly against a hardened and ground housing bore, maximizing the radial load carrying area and structural density within a minimized radial cross-section.
• Dimensional Set: Compact industrial metric architecture providing a 30 mm inner bore diameter, a 46.5 mm outer roller assembly diameter boundary, and a 27 mm total width profile.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
