056SPA3 RICH V-Belt 56x50 PT056SPA3 RICH
search
  • 056SPA3 RICH V-Belt 56x50 PT056SPA3 RICH

056SPA3 RICH V-Belt 56x50

RICH
PT056SPA3
€4.06
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

056SPA3 RICH V-Belt Pulley Diameter 56 mm, Width 50 mm

Technical Specifications

  • Catalog Code: 056SPA3
  • Brand: RICH
  • Type: V-Belt Pulley
  • Profile: SPA
  • Number of Grooves: 3
  • Material: Grey Cast Iron
  • Outer Diameter (dw): 56 mm
  • Width (W): 50 mm
  • L [mm]: 54
  • M [mm]: 40
  • Z [mm]: 4
  • Execution: 4-4A
  • Mounting: With Solid Hub
  • Features: Pulley with Hub, Pulley with Center Holes
  • Weight: 0.7 kg
  • Country of Origin: China

Key Features

  • Designed for SPA profile belts with 3 grooves.
  • Solid hub construction for durability and stability.
  • Made of grey cast iron for strength and long service life.
  • Compact design with center holes for precise alignment.

Data sheet

Outer Diameter
56
Width
50
