HM88630/HM88610 RICH 25,4x72,23x25,4

HM88630/HM88610 RICH – Tapered Roller Bearing – 25.4 x 72.233 x 25.4 mm

Technical Specifications:

• Type: Single row tapered roller bearing
• Brand: RICH
• Model Designation: HM88630/HM88610
• Inner Diameter (d): 25.4 mm
• Outer Diameter (D): 72.233 mm
• Total Width (T): 25.4 mm
• Inner Ring Width (B): 25.4 mm
• Outer Ring Width (C): 19.842 mm
• Weight: 0.595 kg
• Cage Material: Steel
• Country of Origin: China

Product Details:

• Separable Components: Modular structure consisting of an inner ring assembly with rollers and steel cage (HM88630 cone) and a separate matching outer ring (HM88610 cup).
• Row Configuration: Internal design based on a single row of tapered rolling elements aligned by a steel guiding cage.
• Dimensional Format: Imperial-based geometric layout defined by specified inner bore, outer diameter, individual ring widths, and total assembled width.

Transparency Note: This bearing is manufactured under the RICH brand. OE and interchangeable references are provided solely for identification and do not imply affiliation with the original manufacturers.
