F-566312.02 RICH 31,750x73,025x16,669

Type: Single Row Angular-Contact Ball Bearing (Single Thrust)
Model: F-566312.02 RICH
Dimensions: 31.75 x 73.025 x 16.669 mm
Inner Ring Width: 13.891 mm
Weight: 0.285 kg
Brand: RICH
Origin: China
RICH
F-566312.02
€19.88
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

F-566312.02 RICH | Single Row Angular-Contact Ball Bearing – 31.75 x 73.025 x 16.669 mm

Technical Specifications:

  • Catalog Code: F-566312.02 RICH
  • Brand: RICH
  • Type: Single row angular-contact ball bearing, single thrust
  • Bore Diameter (d): 31.750 mm
  • Outer Diameter (D): 73.025 mm
  • Total Width (T): 16.669 mm
  • Inner Ring Width (B): 13.891 mm
  • Weight: 0.285 kg
  • Country of Origin: China

Key Performance Advantages:

  • Single row angular-contact design optimized for supporting axial thrust loads in one direction.
  • Precision inch‑series geometry suitable for specialized industrial and automotive applications.
  • Compact width (16.669 mm) enabling installation in tight axial spaces.
  • High rotational stability thanks to optimized raceway and ball alignment.

Transparency Note: This bearing is manufactured under the RICH brand. The code F‑566312.02 is used solely for identification and does not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
31,75
Outer Diameter
73,025
Width
16,669
Weight
0,285
Clearance
CN (Normal)
Category
Single Row Angular-Contact Ball Bearing
