• New
5205 NR RICH 25x52x20,6 5205NR RICH
zoom_out_map
5205 NR RICH 25x52x20,6 5205NR RICH

5205 NR RICH 25x52x20,6

Type: Double Row Angular-Contact Ball Bearing
Model: 5205 NR RICH
Dimensions: 25 x 52 x 20.6 mm
Features: Snap Ring (NR), Open Design, Steel Cage
Brand: RICH
Origin: China
RICH
5205NR
€6.72
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

5205 NR RICH – Double Row Angular-Contact Ball Bearing – 25 x 52 x 20.6 mm

Technical Specifications:

  • Type: Double row angular-contact ball bearing
  • Brand: RICH
  • Model Designation: 5205 NR
  • Inner Diameter (d): 25 mm
  • Outer Diameter (D): 52 mm
  • Width (B): 20.6 mm
  • Sealing: Open (No sealing)
  • Mounting Feature: NR (Snap ring groove with snap ring on the outer ring)
  • Internal Clearance: CN (Normal clearance)
  • Cage Material: Steel
  • Weight: 0.193 kg
  • Country of Origin: China

Performance Characteristics:

  • Structural Configuration: Double-row angular contact design providing high rigidity and the ability to support tilting moments.
  • Mounting Interface: Equipped with a snap ring (NR) on the outer ring to facilitate precise axial location and simplified mounting within the housing.
  • Load Capability: Specifically engineered to accommodate substantial radial loads and axial loads in both directions simultaneously.
  • Mechanical Interface: 25 x 52 x 20.6 mm dimensional format manufactured according to industrial precision tolerances for high-performance rotary systems.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
25
Outer Diameter
52
Width
20,6
Weight
0,193
Ball Rows
Double Row
Category
Double Row Angular-Contact Ball Bearing
