5209-2RS RICH 45x85x30,2

5209-2RS RICH – Double Row Angular Contact Ball Bearing – 45 x 85 x 30.2 mm

Technical Specifications:

• Type: Double row angular contact ball bearing
• Brand: RICH
• Model Designation: 5209-2RS
• Inner Diameter (d): 45 mm
• Outer Diameter (D): 85 mm
• Width (B): 30.2 mm
• Internal Clearance: CN (Normal)
• Cage Material: Steel
• Sealing: Double-sided rubber contact seals (2RS)
• Weight: 0.689 kg
• Country of Origin: China

Performance Characteristics:

• Structural Configuration: Double row design corresponding to two single row angular contact ball bearings arranged back-to-back, requiring less axial space.
• Load Management: Engineered to support radial loads and axial loads in both directions, providing high tilting stiffness and rigid displacement control.
• Sealing and Protection: Equipped with integrated contact rubber seals (2RS) on both sides to retain factory lubrication and exclude moisture and debris.
• Dimensional Format: 45 x 85 x 30.2 mm profile manufactured according to standardized industrial tolerances for heavy-duty mechanical reliability.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
