5216 2RS RICH 80x140x44,4

5216 2RS RICH – Double Row Angular Contact Ball Bearing – 80 x 140 x 44.4 mm

Technical Specifications:

• Type: Double row angular contact ball bearing
• Brand: RICH
• Model Designation: 5216 2RS
• Inner Diameter (d): 80 mm
• Outer Diameter (D): 140 mm
• Width (B): 44.4 mm
• Cage Material: Steel
• Radial Internal Clearance: CN (Normal clearance)
• Sealing: Rubber seals on both sides, contact type (2RS)
• Weight: 2.46 kg
• Country of Origin: China

Construction Features:

• Component Design: The unit is engineered with integrated, double-sided contact rubber seals to prevent contamination and retain lubricant.
• Row Configuration: The internal layout features a double row configuration of angular contact rolling elements secured by a steel cage.
• Dimensional Profile: The structural framework is defined by an 80 mm internal bore, a 140 mm outside diameter, and an axial width of 44.4 mm.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
