BTH1011 RICH 55x90x60

Type: Double Row Tapered Roller Bearing
Model: BTH1011 RICH
OE References: IVECO 504207325, FIAT 1346650080, PEUGEOT 3326.69
Interchange: SKF BTH1011, FAG 713690840, SNR R141.03
Dimensions: 55 x 90 x 60 mm
Features: Double Non-Contact Shields, High Load Stability
Brand: RICH
Origin: China
RICH
BTH1011
€19.22
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

BTH1011 RICH – Double Row Tapered Roller Bearing – 55 x 90 x 60 mm

OE Reference:

  • IVECO: 504207325, 503645071, 503643937, 46393024, 42558516, 7187566, 7180066
  • FIAT: 1346650080, 1328054080
  • PEUGEOT / CITROEN: 3326.69, 3326.63
  • RENAULT TRUCKS: 7485139097
  • NISSAN: 43210-LC42A

Interchange / Cross-References:

  • SKF: BTH1011, VKBA3552, VKBA3641, VKBA3690, VKBC20022
  • FAG: 713690840, 713690940, 101525, 101663
  • SNR: R140.14, R140.38, R141.03
  • FERSA: F15121, KB362, KB372

Technical Specifications:

  • Type: Double row tapered roller bearing
  • Brand: RICH
  • Model Designation: BTH1011
  • Inner Diameter (d): 55 mm
  • Outer Diameter (D): 90 mm
  • Total Width (T): 60 mm
  • Sealing: ZZ (Double-sided non-contact shields)
  • Weight: 1.439 kg
  • Country of Origin: China

Performance Characteristics:

  • Structural Configuration: Integrated double-row tapered roller assembly, specifically designed for heavy-duty automotive wheel hubs and commercial vehicle axles.
  • Load Capability: Engineered to support extreme radial loads and simultaneous axial thrust in both directions, providing superior stability for light commercial vehicles.
  • Sealing System: Features double-sided non-contact shields to retain internal grease and protect the rollers from environmental debris without increasing rotational friction.
  • Mechanical Interface: 55 x 90 x 60 mm dimensional format manufactured to precision industrial standards for direct interchangeability with original equipment hub units.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
55
Outer Diameter
90
Width
60
Roller Rows
Double Row
Category
Double Row Tapered Roller Bearing
