SAC 3055-1 RICH Single Row Angular Contact Ball Bearing – 30 × 55 × 17 mm
OE References:
- HONDA 91016KT8-0050
- YAMAHA 933999993200
- NTN SF0649PX1
Technical Specifications:
- Type: Single row angular-contact ball bearing
- Brand: RICH
- Model Designation: SAC 3055-1 RICH
- Inner Diameter (d): 30 mm
- Outer Diameter (D): 55 mm
- Total Width (T): 17 mm
- Inner Ring Width (B): 10.95 mm
- Outer Ring Width (C): 6 mm
- Application Category: Steering head bearing
- Weight: 0.12 kg
- Sealing: None (Open bearing)
- Country of Origin: China
Performance Characteristics:
- Structural Layout: Single row radial-axial ball bearing.
- Internal Geometry: Angular contact raceways for the distribution of radial and axial loads.
- Material Composition: High-carbon chromium steel rings and rolling elements.
- Lubrication: Open configuration without integrated sealing elements.
- Dimensional Format: 30 × 55 × 17 mm configuration.
Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
