SFL205 RICH

SFL205 RICH – Stainless Steel Flange Housing – 25 mm

Technical Specifications:

• Type: 2-Bolt Oval Flange Housing
• Brand: RICH
• Model Designation: SFL205
• Material: AISI 304 Stainless Steel
• Compatible Bearing Bore: 25 mm
• Total Length (L): 130 mm
• Pitch Circle Diameter (J): 99 mm
• Housing Width (A): 27 mm
• Flange Thickness (A1): 13 mm
• Housing Height (L2): 68 mm
• Bolt Hole Size (N): 16 mm
• Weight: 0.335 kg
• Country of Origin: China

Construction Features:

• Material Excellence: Manufactured from high-grade stainless steel for superior corrosion resistance in wash-down and chemical environments.
• Oval Flange Design: Compact 2-bolt configuration (SFL series) ideal for applications with limited mounting space.
• Maintenance: Equipped with a lubrication fitting for easy relubrication of the insert bearing.
• Compatibility: Specifically designed for series 205 stainless steel or chrome steel insert ball bearings.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
