SS 2208 2RS RICH 40x80x23

SS 2208.2RS RICH – Stainless Steel Self-Aligning Ball Bearing – 40 x 80 x 23 mm

Technical Specifications:

• Type: Self-aligning ball bearing
• Brand: RICH
• Model Designation: SS 2208.2RS
• Material: Stainless steel
• Inner Diameter (d): 40 mm
• Outer Diameter (D): 80 mm
• Width (B): 23 mm
• Internal Clearance: CN (Normal clearance)
• Sealing: Double-sided rubber contact seals (2RS)
• Weight: 0.525 kg
• Country of Origin: China

Product Details:

• Components: A stainless steel inner ring with two raceway grooves, a stainless steel outer ring with a continuous spherical raceway surface, a double row of rolling elements, and double-sided synthetic rubber contact lips.
• Internal Geometry: Engineered with a center-point spherical outer raceway that permits the ball and cage complement to pivot freely around the bearing center, automatically compensating for dynamic misalignment and shaft deflection.
• Dimensional Set: Standardized metric configuration containing a 40 mm cylindrical bore, an 80 mm outside diameter, and a 23 mm cross-sectional width.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
