GE 35 AX RICH 35x90x28

GE 35 AX RICH – Spherical Plain Thrust Bearing – 35 x 90 x 28 mm

Technical Specifications:

• Type: Spherical plain thrust bearing
• Brand: RICH
• Model Designation: GE 35 AX
• Inner Diameter (d): 35 mm
• Outer Diameter (D): 90 mm
• Total Width (T): 28 mm
• Inner Ring Width (B): 22 mm
• Outer Ring Width (C): 20 mm
• Outer Diameter of Inner Ring (Dw): 84 mm
• Inner Diameter of Outer Ring (dz): 50.5 mm
• Friction Pair: Steel / Steel
• Weight: 1.06 kg
• Country of Origin: China

Construction Features:

• Component Design: The unit consists of a shaft washer with a sphered outer surface and a housing washer with a matching sphered inner surface to accommodate axial loads.
• Sliding Contact Surface: The internal operating interface utilizes a steel-on-steel sliding friction configuration requiring regular lubrication.
• Dimensional Profile: The structural layout features a 35 mm bore, a 90 mm housing washer outside diameter, and an overall assembled width of 28 mm.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
