N-314 RICH 70x150x35

N314 RICH Single Row Cylindrical Roller Bearing - 70 x 150 x 35 mm with Steel Cage

The N314 RICH is a robust single row cylindrical roller bearing meticulously engineered to accommodate substantial radial loads. Its fundamental design comprises cylindrical rollers and precisely ground raceways on both the inner and outer rings. The linear contact between these components over a significant area facilitates an exceptional capacity for transmitting radial forces, making it well-suited for applications subjected primarily to this type of loading.

This bearing incorporates a steel cage, which serves a critical function in maintaining the accurate circumferential spacing of the cylindrical rollers. This precise separation prevents roller-to-roller contact during operation, thereby minimizing frictional heat generation and wear. Furthermore, the cage ensures optimal roller guidance within the load zone and during periods of non-load, contributing to the overall operational efficiency and longevity of the bearing.

The principal dimensions of the N314 RICH are 70 mm inner diameter (d), allowing for mounting on a correspondingly sized shaft; 150 mm outer diameter (D), designed to fit within a specific housing bore; and a width of 35 mm (B), which dictates the axial extent of the bearing assembly. The bearing's weight of approximately 2.972 kg is indicative of its substantial construction and load-bearing capabilities.

Cylindrical roller bearings of this configuration are non-locating bearings, meaning they do not provide axial restraint. Axial movement between the shaft and housing is permissible. This characteristic is often advantageous in applications where thermal expansion of shafts needs to be accommodated or where external means of axial location are implemented.

The manufacturing of this bearing by RICH in China adheres to stringent quality control standards to ensure dimensional accuracy, material integrity, and operational reliability. The high-quality steel used in both the rollers and raceways is typically through-hardened to provide optimal resistance to fatigue and wear under demanding operating conditions.

Key Specifications:

• Type: Single Row Cylindrical Roller Bearing
• Dimensions: 70 mm inner diameter (d) x 150 mm outer diameter (D) x 35 mm width (B)
• Weight: 2.972 kg
• Cage Material: Steel
• Country of Origin: China
• Brand: RICH

Key Advantages:

• Exceptional Radial Load Capacity: Optimized design for handling heavy radial forces due to the large contact area of the cylindrical rollers.
• Enhanced Operational Efficiency: The steel cage ensures precise roller spacing and guidance, minimizing friction and wear.
• Robust Construction: The substantial weight and material selection indicate a bearing capable of withstanding demanding industrial environments.
• Accommodation of Axial Movement: Non-locating design allows for axial displacement between the shaft and housing, crucial in applications with thermal expansion.
• Dimensional Precision: Manufactured to tight tolerances to ensure accurate fit and reliable performance within machinery.
• Versatile Industrial Application: Suitable for a wide array of heavy-duty machinery, including gearboxes, electric motors, pumps, and rolling mill stands.
