KM 1 RICH 12x22x4 KM1 RICH
zoom_out_map
KM 1 RICH 12x22x4 KM1 RICH

KM 1 RICH 12x22x4

KM 1 Locknut by RICH. Dimensions 12 x 22 x 4 mm with M12x1 thread. Secures bearings on a shaft, preventing loosening and ensuring stable axial location.

RICH
KM1
€0.49
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

KM 1 RICH Locknut - 12 x 22 x 4 mm

Technical Specifications:

  • Product Type: Locknut
  • Model Designation: KM 1
  • Brand: RICH
  • Thread Size: M12x1
  • Bore Diameter (d): 12 mm
  • Outer Diameter (D): 22 mm
  • Width (B): 4 mm
  • Weight: 0.006 kg
  • Country of Origin: China

The KM 1 RICH is a standard locknut designed to be used with corresponding lock washers (not included) to reliably secure rolling bearings, sleeves, and other components onto a shaft. This small, crucial component features an M12x1 thread and provides essential axial support to maintain the correct positioning of assemblies. With precise dimensions of 12 mm bore, 22 mm outer diameter, and 4 mm width, the KM 1 RICH offers a lightweight and dependable solution for mounting and setting the clearance or preload of small bearing arrangements in machinery where space is limited.

Key Performance Advantages:

  • Secure Axial Positioning: Effectively locks components against axial movement on the shaft.
  • Standard Thread: Features an M12x1 thread for common industrial applications.
  • Compact Design: Small dimensions (12 x 22 x 4 mm) ideal for space-constrained assemblies.
  • RICH Quality: A reliable retaining nut for ensuring assembly integrity and performance.

Data sheet

Inner Diameter
12
Outer Diameter
22
Width
4
Weight
0,006
Category
Locknut
