SA 201 RICH 12x40x28.6

The SA 201 RICH insert ball bearing (12 x 40 x 28.6 mm) features a flat outer ring, C3 clearance, and double-sided contact rubber seals for secure mounting and maximum protection.

RICH
SA201
€3.08
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

SA 201 RICH Insert Ball Bearing with Flat Outer Ring - 12 x 40 x 28.6 mm

Technical Specifications:

  • Product Type: Ball Bearing with Flat Outer Ring (Insert Bearing)
  • Model Designation: SA 201
  • Brand: RICH
  • Bore Diameter (d): 12 mm
  • Outer Diameter (D): 40 mm
  • Outer Ring Width (C): 12 mm
  • Inner Ring Width (B): 23.8 mm
  • Total Width (T): 28.6 mm
  • Clearance: C3 - Greater than normal
  • Sealing: Double-sided rubber, contact type
  • Outer Ring Profile: Flat (Cylindrical)
  • Weight: 0.136 kg
  • Country of Origin: China

The SA 201 RICH is a specialized insert ball bearing featuring a flat (cylindrical) outer ring, designed for use in cylindrical housings where the outer ring does not need to self-align. With dimensions of 12 mm bore, 40 mm outer diameter, and 28.6 mm total width (T), this bearing is engineered for stability and durability. It is equipped with double-sided contact rubber seals for excellent protection against moisture and contaminants, making it suitable for demanding industrial and agricultural environments. The C3 clearance (greater than normal) allows for thermal expansion and ensures reliable operation under conditions where the inner ring may reach higher temperatures than the outer ring.

Key Performance Advantages:

  • Flat Outer Ring: Ensures precise fitting into cylindrical housing bores.
  • C3 Clearance: Optimized for applications involving high operating temperatures or potential misalignment.
  • Contact Rubber Seals: Provides superior protection against the ingress of dust, dirt, and water.
  • Compact Design: Total width of 28.6 mm offers a space-saving solution for secure mounting.
  • RICH Quality: A high-quality component ensuring long-term operational excellence.

Data sheet

Inner Diameter
12
Outer Diameter
40
Width
28,6
Weight
0,136
Ball Rows
Single Row
Clearance
C3 (Greater than Normal)
