W209PPB30 RICH 30x90x45

RICH
W209PPB30
€15.19
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

W209PPB30 RICH Insert Ball Bearing with Square Hole - 30 x 90 x 45 mm

Technical Specifications:

  • Brand: RICH
  • Type: Insert Ball Bearing with Square Hole
  • Bore (d): 30 mm
  • Outer Diameter (D): 90 mm
  • Outer Ring Width (C): 29 mm
  • Inner Ring Width: 45 mm
  • Weight: 1.018 kg
  • Sealing: Triple-lip seal, covered with metal plate on both sides
  • Outer Ring: Rounded
  • Country of Origin: China

The W209PPB30 RICH is a heavy-duty insert ball bearing specifically engineered for demanding agricultural and industrial applications. The unique square hole allows for quick and secure mounting onto a square shaft, providing a positive lock against rotation without the need for set screws or adapters. This bearing features a rounded outer ring, enabling it to accommodate initial misalignment within a housing. A defining feature is its robust triple-lip sealing system, which is covered with a metal plate on both sides to provide maximum protection against heavy contamination and debris, ensuring a long and reliable service life in the harshest environments.

Key Performance Advantages:

  • Secure Square Bore: Ensures a firm, anti-rotation fit on square shafts, simplifying installation.
  • Extreme Contamination Protection: Triple-lip seals with metal plates provide superior defense against dirt, dust, and moisture.
  • Accommodates Misalignment: The rounded outer ring allows for angular misalignment, reducing stress.
  • Durable Construction: Built for low-speed, heavily contaminated applications, offering exceptional durability.
  • RICH Quality: Delivers dependable and consistent performance.

Data sheet

Inner Diameter
30
Outer Diameter
90
Width
45
Weight
1,018
