UCFB 204 RICH UCFB204 RICH
zoom_out_map
UCFB 204 RICH UCFB204 RICH

UCFB 204 RICH

The UCFB204 RICH cast iron bearing unit features a 4-bolt square flange, a 20 mm bore insert with CN clearance, and self-aligning capability for robust, fixed shaft mounting.

RICH
UCFB204
€4.22
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

UCFB204 RICH Cast Iron Bearing Unit - 20 mm Bore (4-Bolt Flange)

Technical Specifications:

  • Product Type: Cast Iron Bearing Unit (4-Bolt Flange)
  • Model Designation: UCFB204
  • Brand: RICH
  • Bore Diameter (d): 20 mm
  • Flange Side Length (L): 62 mm
  • Bolt Hole Center Distance (J): 32 mm
  • Overall Height (H): 42 mm
  • Clearance: CN - Normal Clearance
  • Weight: 0.568 kg
  • Country of Origin: China

The UCFB204 RICH is a reliable cast iron bearing unit featuring a 4-bolt square flange housing, specifically designed for applications requiring precise, fixed mounting to a machine frame. The rugged cast iron construction provides superior stability and shock absorption. The unit includes a self-aligning bearing insert with a 20 mm bore and CN (Normal) clearance, which is securely locked to the shaft (locking mechanism implied by UC insert type). The self-aligning feature allows the unit to compensate for initial shaft misalignment, ensuring prolonged bearing life and smooth operation. The UCFB204 RICH, with its compact design and 32 mm bolt hole center distance (J), is an excellent choice for conveyor heads, transmissions, and industrial fan assemblies.

Key Performance Advantages:

  • 4-Bolt Flange Housing: Provides a stable, fixed, and highly secure mounting solution.
  • Cast Iron Rigidity: Ensures durability and excellent performance in tough operating conditions.
  • Self-Aligning: Compensates for static mounting errors and dynamic shaft deflection.
  • RICH Quality: A robust unit providing reliable shaft support for industrial machinery.
