FTD SPZ 1340 RICH V-Belt FTDSPZ1340 RICH
search
  • FTD SPZ 1340 RICH V-Belt FTDSPZ1340 RICH

FTD SPZ 1340 RICH V-Belt

RICH
FTDSPZ1340
€3.23
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

The minimum purchase order quantity for the product is 10.

Rating:
(0)

SPZ 1340 FTD RICH Toothed V-Belt – 9.7 x 8 mm Section – 1327 mm Inside Length

Reference Standard

All RICH SPZ series belts are described according to ISO 4184 / DIN 7753, which use the Pitch Length (Lp) as the reference dimension. From Lp, the Inside Length (Li) and Outside Length (La) are derived with fixed offsets. Some suppliers may report different values (e.g., using Li or La as the reference), but these are the same belts, simply measured under different conventions.

Technical Specifications

  • Product Type: V-Belt
  • Model Designation: SPZ 1340 FTD
  • Brand: RICH
  • Profile: SPZ
  • Pitch Length (Lp): 1340 mm
  • Inside Length (Li): 1327 mm
  • Outside Length (La): 1353 mm
  • Belt Width (bo): 9.7 mm
  • Belt Thickness (h): 8 mm
  • Tensile Cord: Polyester
  • Material: Reinforced rubber
  • Construction: Cut-edge, notched back (FTD type)
  • Country of Origin: China

Key Advantages

  • Superior Flexibility: Toothed design allows use with smaller pulley diameters and ensures efficient power transfer.
  • High Efficiency: Reduces heat build-up and energy loss compared to wrapped belts.
  • Enhanced Durability: Reinforced rubber and polyester cords provide excellent wear resistance and tensile strength.
  • Precision Fit: Guarantees optimal transmission and reduced slippage.

Transparency Note

Lengths shown follow ISO 4184 / DIN 7753. Some suppliers may indicate slightly different values (e.g., rounding width to 10 mm or using Li as the reference), but these are the same belts. RICH specifications ensure international consistency and technical defensibility.
