FTD SPZ 1362 RICH V-Belt
Rating:
(0)
EUR €
- EUR €
- USD $
SPZ 1362 FTD RICH Toothed V-Belt – 9.7 x 8 mm Section – 1349 mm Inside Length
Reference Standard
All RICH SPZ series belts are described according to ISO 4184 / DIN 7753, which define the Pitch Length (Lp) as the reference dimension. From Lp, the Inside Length (Li) and Outside Length (La) are derived with fixed offsets. Some suppliers may report different values (e.g., using Li or La as the reference, or rounding width to 10 mm), but these are the same belts, simply expressed under different conventions.
Technical Specifications
- Product Type: V-Belt
- Model Designation: SPZ 1362 FTD
- Brand: RICH
- Profile: SPZ
- Pitch Length (Lp): 1362 mm
- Inside Length (Li): 1349 mm
- Outside Length (La): 1375 mm
- Belt Width (bo): 9.7 mm
- Belt Thickness (h): 8 mm
- Tensile Cord: Polyester
- Material: Reinforced rubber
- Construction: Cut-edge, notched back (FTD type)
- Country of Origin: China
Key Advantages
- Superior Flexibility: Toothed design allows use with smaller pulley diameters and ensures efficient power transfer.
- High Efficiency: Reduces heat build-up and energy loss compared to wrapped belts.
- Enhanced Durability: Reinforced rubber and polyester cords provide excellent wear resistance and tensile strength.
- Precision Fit: Guarantees optimal transmission and reduced slippage.
Transparency Note
Lengths shown follow ISO 4184 / DIN 7753. Other suppliers may indicate slightly different values (e.g., rounding width to 10 mm or using Li as the reference), but these are the same belts. RICH specifications ensure international consistency, transparency, and technical defensibility across all catalog entries.
Data sheet
Weight
0,101
