RD-04A34 (SX04A34V1) RICH 22x65x18

RD-04A34 RICH is a single row deep groove ball bearing, interchangeable with HONDA OE 91004-PL3-A03 and NTN SX04A34V1.

RICH
SX04A34V1
€7.01
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

RD-04A34 RICH | Single Row Deep Groove Ball Bearing – 22 x 65 x 18 mm

OE References:

  • HONDA: 91004-PL3-A03

Interchange:

  • NTN: SX04A34V1

Technical Specifications:

  • Catalog Code: RD-04A34 RICH
  • Brand: RICH
  • Type: Single Row Deep Groove Ball Bearing
  • Bore Diameter (d): 22 mm
  • Outer Diameter (D): 65 mm
  • Total Width (B/T): 18 mm
  • Outer Ring Width (C): 17 mm
  • Cage: Polyamide
  • Sealing: None (Open)
  • Weight: 0.271 kg
  • Country of Origin: Made in China

Key Performance Advantages:

  • Deep Groove Geometry: Provides excellent radial and axial load capacity.
  • Polyamide Cage: Lightweight, reduces friction, and suitable for high-speed applications.
  • OEM Compatibility: Suitable replacement for HONDA OE reference 91004-PL3-A03.
  • Interchangeable: Equivalent to NTN SX04A34V1.
  • Durable Construction: Precision engineered for reliability under demanding operating conditions.

Transparency Note: This bearing is manufactured under the RICH brand. The code RD-04A34, OE references, and interchange are used solely for identification and do not imply affiliation with HONDA, NTN or other brands. The product is clearly marked with its actual brand and origin (Made in China).

Data sheet

Inner Diameter
22
Outer Diameter
65
Width
18
Weight
0,271
Ball Rows
Single Row
Cage
Polyamide Cage
Clearance
CN (Normal)
Category
Single Row Deep Groove Ball Bearing
