Type: Inner Ring
Model: IR 50x60x40 RICH
Dimensions: 50 x 60 x 40 mm
Application: Precision Raceway for Needle Bearings
Brand: RICH
Origin: China
RICH
IR50x60x40
€3.17
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

IR 50x60x40 RICH Inner Ring - 50 x 60 x 40 mm

Technical Specifications:

  • Catalog Code: IR 50x60x40 RICH
  • Brand: RICH
  • Type: Inner ring for needle roller bearings
  • Bore Diameter (d): 50 mm
  • Outer Diameter (F): 60 mm
  • Width (B): 40 mm
  • Weight: 0.267 kg
  • Country of Origin: China

Product Overview:

The IR 50x60x40 RICH is a high-precision inner ring designed to provide an optimal raceway surface for needle roller bearings in applications where the shaft cannot be hardened and ground. Engineered to exacting tolerances, this component ensures smooth rotation and high load-carrying capacity by offering a precision-finished running surface for the rolling elements. This inner ring is particularly useful in heavy-duty machinery, automotive transmissions, and industrial pumps where shaft integrity must be maintained. Manufactured from high-quality bearing steel, it features excellent wear resistance and dimensional stability under thermal stress. Its universal design allows for seamless integration into various mechanical assemblies, providing a cost-effective and reliable alternative to direct shaft machining.

Key Performance Advantages:

  • Precision Raceway Surface: Fine-ground finish reduces friction and noise while extending the service life of the needle roller assembly.
  • Versatile Application: Ideal for use with needle roller and cage assemblies or needle roller bearings with open or closed ends.
  • High-Grade Material: Constructed from premium steel to withstand significant radial loads and resist mechanical fatigue.
  • Shaft Protection: Eliminates the need for expensive shaft hardening and grinding, simplifying maintenance and assembly.

Transparency Note: This component is manufactured under the RICH brand. The code IR 50x60x40 is used solely for identification and does not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
50
Outer Diameter
60
Width
40
Weight
0,267
