LFR50/8-6-2RS RICH 8x24x11 LFR50/8-6-2RS RICH
search
  • LFR50/8-6-2RS RICH 8x24x11 LFR50/8-6-2RS RICH

LFR50/8-6-2RS RICH 8x24x11

RICH
LFR50/8-6-2RS
€7.08
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

LFR50/8-6-2RS RICH Track Roller with Profiled Outer Ring - 8 x 24 x 11 mm

Technical Specifications:

  • Catalog Code: LFR50/8-6-2RS RICH
  • Brand: RICH
  • Type: Track roller with Gothic arch profiled outer ring
  • Inner Diameter (d): 8 mm
  • Outer Diameter (D): 24 mm
  • Width (B): 11 mm
  • Shaft Diameter (ds): 6 mm
  • Sealing: 2RS (Double-sided rubber contact seals)
  • Weight: 0.03 kg
  • Country of Origin: China

Key Performance Advantages:

  • Gothic Arch Profile: The outer ring features a specialized groove designed for optimal contact with 6 mm diameter shafts, ensuring smooth linear guidance and high stability.
  • Double Row Design: Built with an internal double-row angular contact ball structure to accommodate high radial loads and axial loads from both directions.
  • Effective 2RS Sealing: Equipped with contact rubber seals on both sides to prevent the ingress of dirt and maintain lubrication in dusty environments.
  • Low Friction Operation: Engineered for high-speed applications and quiet running, making it ideal for linear motion systems and textile machinery.

Transparency Note: This product is manufactured under the RICH brand. The code LFR50/8-6-2RS is used for identification purposes and does not imply affiliation with other manufacturers.

Data sheet

Inner Diameter
8
Outer Diameter
24
Width
11
