CYR-7/8-S RICH 6,35x22,225x14,287 CYR-7/8-S RICH
search
  • CYR-7/8-S RICH 6,35x22,225x14,287 CYR-7/8-S RICH

CYR-7/8-S RICH 6,35x22,225x14,287

RICH
CYR-7/8-S
€6.58
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

CYR-7/8-S RICH Yoke Roller - Cylindrical Outer Ring - 6.35 x 22.225 x 14.287 mm

Technical Specifications:

  • Product Type: Yoke Roller
  • Model Designation: CYR-7/8-S
  • Brand: RICH
  • Inner Diameter (ID): 6.35 mm
  • Outer Diameter (OD): 22.225 mm
  • Inner Ring Width (B/H): 14.287 mm
  • Outer Ring Width (C): 12.7 mm
  • Outer Ring Profile: Cylindrical (Non-rounded)
  • Sealing: Double-sided Rubber, Contact
  • Cage: None (Full Complement)
  • Weight: 0.034 kg
  • Country of Origin: China

The CYR-7/8-S RICH is a heavy-duty yoke roller designed for reliable load support and guidance in track-type and cam drive mechanisms. This precision roller features a cylindrical outer ring for maximum contact on flat surfaces and is protected by double-sided contact rubber seals to prevent contamination and retain lubrication, ensuring long service intervals. Operating with a full complement of rolling elements (no cage), it provides high load-carrying capacity. With core dimensions of 6.35 mm bore, 22.225 mm outer diameter, and an inner ring width of 14.287 mm, the CYR-7/8-S RICH offers a robust and dependable solution for high-load applications requiring reliable tracking.

Key Performance Advantages:

  • Cylindrical Outer Ring: Ideal for maximizing load distribution on flat guide surfaces.
  • Double-sided Contact Seals: Excellent protection against dust, dirt, and moisture ingress.
  • Full Complement Design: Enhanced radial load-carrying capacity without a cage.
  • RICH Quality: A durable component built for continuous operation in industrial tracks.

Data sheet

Inner Diameter
6,35
Outer Diameter
22,225
Width
14,287
