3308 M RICH 40x90x36,5
3308 M RICH Angular-Contact Ball Bearing – double row design with brass cage guided by rolling elements. Dimensions 40 x 90 x 36.5 mm, weight 0.91 kg. Ensures high rigidity, durability, and long service life.
3308 M RICH | Double Row Angular-Contact Ball Bearing – 40 x 90 x 36.5 mm
Technical Specifications:
- Catalog Code: 3308 M RICH
- Brand: RICH
- Type: Double Row Angular-Contact Ball Bearing
- Inner Diameter (d): 40 mm
- Outer Diameter (D): 90 mm
- Width (B): 36.5 mm
- Weight: 0.91 kg
- Cage: Brass, guided by the rolling elements
- Internal Clearance: CN – Normal clearance
- Sealing: None (open execution)
- Country of Origin: China
Key Performance Advantages:
- Double Row Angular-Contact Design: Provides high rigidity and supports combined radial and axial loads.
- Brass Cage: Guided by rolling elements for enhanced durability and heat resistance.
- Normal Clearance (CN): Balanced play for general-purpose applications.
- Open Execution: No seals, suitable for environments with controlled lubrication.
- RICH Quality: Precision manufactured for durability and consistent performance.
Transparency Note: This double row angular-contact ball bearing is manufactured directly under the RICH brand. The catalog code 3308 M is used solely for identification and does not imply affiliation with other brands. The product is clearly marked with its actual brand and origin.
Data sheet
Inner Diameter
40
Outer Diameter
90
Width
36,5
Ball Rows
Double Row
Cage
Brass
Clearance
CN (Normal)
Category
Double Row Angular-Contact Ball Bearing
