5214 M RICH 70x125x39,7

5214 M RICH – Double Row Angular Contact Ball Bearing – 70 x 125 x 39.7 mm

Technical Specifications:

• Type: Double row angular contact ball bearing
• Brand: RICH
• Model Designation: 5214 M
• Inner Diameter (d): 70 mm
• Outer Diameter (D): 125 mm
• Width (B): 39.7 mm
• Internal Clearance: CN (Normal)
• Cage Material: Machined brass (Rolling element guided)
• Sealing: None (Open)
• Weight: 1.96 kg
• Country of Origin: China

Performance Characteristics:

• Structural Configuration: Double row angular contact assembly designed for robust radial and axial load support in both directions.
• Cage Specification: Features a solid brass cage guided by the rolling elements, offering superior mechanical stability and heat dissipation in demanding environments.
• Component Geometry: Rigid internal construction designed to maintain precise axial and radial positioning under high-torque conditions.
• Mechanical Interface: 70 x 125 x 39.7 mm dimensional format manufactured to standardized industrial tolerances for consistent rotational performance.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
