5314 TN 2RS RICH 70x150x63,5

5314TN-2RS RICH – Double Row Angular Contact Ball Bearing – 70 x 150 x 63.5 mm

Technical Specifications:

• Type: Double row angular contact ball bearing
• Brand: RICH
• Model Designation: 5314TN-2RS
• Inner Diameter (d): 70 mm
• Outer Diameter (D): 150 mm
• Width (B): 63.5 mm
• Cage Material: Polyamide
• Radial Internal Clearance: CN (Normal clearance)
• Sealing: Rubber seals on both sides, contact type (2RS)
• Weight: 4.682 kg
• Country of Origin: China

Construction Features:

• Component Design: The unit features a protected design with contact rubber seals on both sides to safeguard internal elements.
• Row Configuration: The layout consists of a double row arrangement of angular contact rolling elements retained by a polyamide cage.
• Dimensional Profile: The physical structure incorporates a 70 mm bore diameter, a 150 mm outer diameter, and a width profile of 63.5 mm.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
