5213 TN-2RS RICH 65x120x38,1

5213 TN-2RS RICH – Double Row Angular-Contact Ball Bearing – 65 x 120 x 38.1 mm

Technical Specifications:

• Type: Double row angular-contact ball bearing
• Brand: RICH
• Model Designation: 5213 TN-2RS
• Inner Diameter (d): 65 mm
• Outer Diameter (D): 120 mm
• Width (B): 38.1 mm
• Cage Material: Polyamide (TN)
• Radial Internal Clearance: CN (Normal clearance)
• Sealing: Double-sided rubber, contact type (2RS)
• Weight: 1.72 kg
• Country of Origin: China

Construction Features:

• Component Design: The assembly is equipped with integrated, double-sided contact rubber seals configured to preserve internal lubrication and block environmental particulate matter.
• Internal Configuration: The layout features a double row arrangement of rolling balls situated at opposing contact angles and managed by a lightweight polyamide cage to support multi-directional loads.
• Dimensional Profile: The physical envelope is constructed with a 65 mm internal bore diameter, a 120 mm external diameter, and an axial width measurement of 38.1 mm.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
