3201 2Z RICH Double Row Angular Contact Ball Bearing - 12 x 32 x 15.9 mm

The 3201 2Z RICH is a double row angular contact ball bearing designed to accommodate combined radial and axial loads in both directions. This compact bearing has key dimensions of 12 mm inner diameter, 32 mm outer diameter, and a width of 15.9 mm. It features double-sided non-contact shields and weighs 0.062 kg. It is made in China. Double row angular contact ball bearings provide rigid bearing arrangements and can handle higher loads compared to single row bearings, even in smaller sizes. The non-contact shields offer protection against larger particles while allowing for higher rotational speeds due to reduced friction.

Key Specifications:

  • Bearing Type: Double Row Angular Contact Ball Bearing
  • Model: 3201 2Z RICH
  • Inner Diameter (d): 12 mm
  • Outer Diameter (D): 32 mm
  • Width (B): 15.9 mm
  • Clearance:** CN (Normal)
  • Sealing:** Double-sided Non-contact Shields
  • Weight:** 0.062 kg
  • Country of Origin:** China

Key Features:

  • Double Row Design:** Provides increased load capacity and rigidity in a compact size.
  • Angular Contact:** Suitable for combined radial and axial loads in both directions.
  • Non-contact Shields:** Offers protection against larger contaminants with minimal friction.
  • Versatile Application:** Suitable for various applications where space is limited but combined loads are present and higher speeds are desired.
  • Manufacturing Origin:** Made in China.

Data sheet

Inner Diameter
12
Outer Diameter
32
Width
15,9
Ball Rows
Double Row
Sealing
Cover On Both Sides
Clearance
CN (Normal)
