  • SDA0103 RICH 38x80x34,5 SDA0103 RICH

SDA0103 RICH 38x80x34,5

SDA0103 RICH is a double row angular-contact ball bearing with snap ring groove, OE-compatible with Hyundai references and KBC interchange.

RICH
SDA0103
€21.82
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

SDA0103 RICH | Double Row Angular Contact Ball Bearing – 38 x 80 x 34.5 mm

OE Reference / Interchange:

  • F-846050.SKL – KBC
  • 43226-4A040 – HYUNDAI
  • 43226-4D040 – HYUNDAI

Technical Specifications:

  • Catalog Code: SDA0103 RICH
  • Brand: RICH
  • Type: Double Row Angular-Contact Ball Bearing
  • Bore Diameter: 38 mm
  • Outer Diameter: 80 mm
  • Total Width: 34.5 mm
  • Outer Ring Width (C): 23.9 mm
  • Cage Material: Polyamide
  • Sealing: None
  • Special Feature: Groove on outer ring with snap ring
  • Weight: 0.737 kg
  • Country of Origin: China

Key Performance Advantages:

  • OE-Compatible: Direct replacement for Hyundai references and KBC interchange.
  • Double Row Geometry: Supports combined axial and radial loads with high rigidity.
  • Snap Ring Groove: Facilitates secure positioning in housing applications.
  • Polyamide Cage: Lightweight and low-friction for smooth operation.

Transparency Note: This bearing is manufactured under the RICH brand. The code SDA0103 is used solely for identification and does not imply affiliation with any other brand. The product is clearly marked with its actual brand and origin.

Data sheet

Inner Diameter
38
Outer Diameter
80
Width
34,5
Weight
0,737
Cage
Polyamide Cage
Category
Double Row Angular-Contact Ball Bearing
