UCFB 208 RICH UCFB208 RICH
search
  • UCFB 208 RICH UCFB208 RICH

UCFB 208 RICH

RICH
UCFB208
€11.22
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

UCFB 208 RICH Cast Iron Flanged Bearing Unit - 40 mm Bore

Technical Specifications:

  • Brand: RICH
  • Type: Cast Iron Flanged Bearing Unit (Square)
  • Model: UCFB 208
  • Inner Diameter (d): 40 mm
  • Housing Material: Cast Iron
  • Clearance: CN (Normal Clearance)
  • Overall Width (L): 100 mm
  • Overall Height (H): 60 mm
  • Bolt Hole Spacing (J): 50.8 mm
  • Dimension (A): 36 mm
  • Dimension (A1): 16 mm
  • Dimension (H1): 41 mm
  • Dimension (L2): 50 mm
  • Dimension (F2): 164 mm
  • Weight: 1.74 kg
  • Country of Origin: China

The UCFB 208 RICH is a robust Cast Iron Flanged Bearing Unit manufactured by RICH. This heavy-duty unit features a strong, square cast iron housing that guarantees exceptional stability and simplified four-bolt mounting onto flat machine surfaces.

Designed to accommodate a 40 mm shaft, the UCFB 208 RICH provides essential structural support for high-load industrial power transmission systems, including large industrial fans, heavy conveyors, and process machinery. The dense cast iron construction ensures superior vibration damping and structural integrity. With mounting dimensions of 100 x 60 mm and CN (Normal) clearance, this unit is engineered for reliable, long-term performance in demanding industrial environments.

Key Performance Advantages:

  • Heavy-Duty Housing: Robust cast iron construction offers superior structural strength and vibration damping.
  • Simplified Mounting: Square flanged design allows for easy, secure four-bolt installation on flat surfaces.
  • Shaft Compatibility: Precision-engineered for a 40 mm shaft diameter (UC 208 insert).
  • Industrial Stability: Durable solution ideal for high-load, large-scale industrial applications.

Data sheet

Inner Diameter
40
