UCFB 206 RICH Cast Iron Flanged Bearing Unit - 30 mm Bore
Technical Specifications:
- Brand: RICH
- Type: Cast Iron Flanged Bearing Unit (Square)
- Model: UCFB 206
- Inner Diameter (d): 30 mm
- Housing Material: Cast Iron
- Clearance: CN (Normal Clearance)
- Overall Width (L): 78 mm
- Overall Height (H): 50 mm
- Bolt Hole Spacing (J): 40 mm
- Dimension (A): 31 mm
- Dimension (A1): 13 mm
- Dimension (H1): 29 mm
- Dimension (L2): 39 mm
- Dimension (F2): 130 mm
- Weight: 0.89 kg
- Country of Origin: China
The UCFB 206 RICH is a durable Cast Iron Flanged Bearing Unit manufactured by RICH. This unit features a heavy-duty, square cast iron housing that guarantees stable operation and simplified four-bolt mounting onto structural machine surfaces.
Engineered to accommodate a 30 mm shaft, the UCFB 206 RICH is built for robust power transmission systems, including heavier-duty conveyors, industrial mixers, and large processing machinery where sustained stability and load capacity are essential. The dense cast iron construction provides superior vibration damping and structural strength. With compact mounting dimensions (78 x 50 mm) and CN (Normal) clearance, this unit offers a reliable, long-lasting solution for demanding industrial environments.
Key Performance Advantages:
- Robust Construction: Heavy-duty cast iron housing provides superior structural strength and vibration damping.
- Simplified Mounting: Square flanged design allows for easy, secure four-bolt installation on flat surfaces.
- Shaft Compatibility: Precision-engineered for a 30 mm shaft diameter (UC 206 insert).
- Industrial Reliability: Durable solution ideal for heavy-duty applications requiring high stability.
Data sheet
Inner Diameter
30
Weight
0,89
