JP 10049/10 RICH 100x145x24 JP10049/10 RICH
search
  • JP 10049/10 RICH 100x145x24 JP10049/10 RICH

JP 10049/10 RICH 100x145x24

RICH
JP10049/10
€15.22
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

Rating:
(0)

JP10049/10 RICH Single Row Tapered Roller Bearing - 100 x 145 x 24 mm

The JP10049/10 RICH is a single row tapered roller bearing designed to accommodate combined radial and axial loads. This bearing has key dimensions of 100 mm inner diameter, 145 mm outer diameter, and a width (T) of 24 mm. The outer ring width (C) is 17.5 mm and the inner ring width is 22.5 mm. It weighs 1.15 kg and is made in China. This bearing is known to be used in equipment from several manufacturers and is also known as T4CB 100, with Known OE References: 0002124400 (CLAAS), 000.3426850m2 (DANA SPICER), and 3426850M2 (MASSEY FERGUSON). This bearing type, with its tapered rollers and conical raceways, is well-suited for applications requiring support for both high radial and axial loads in one direction. Due to its internal construction, single row tapered roller bearings are typically mounted in pairs with a second tapered roller bearing.

Key Specifications:

  • Bearing Type: Single Row Tapered Roller Bearing
  • Model:** JP10049/10 RICH
  • Also Known As:** T4CB 100
  • Inner Diameter (d):** 100 mm
  • Outer Diameter (D):** 145 mm
  • Width (T):** 24 mm
  • Outer Ring Width (C):** 17.5 mm
  • Inner Ring Width:** 22.5 mm
  • Weight:** 1.15 kg
  • Country of Origin:** China
  • Known OE References:** 0002124400 (CLAAS), 000.3426850m2 (DANA SPICER), 3426850M2 (MASSEY FERGUSON)

Key Features:

  • Tapered Roller Design:** Optimized for combined radial and axial loads.
  • Separable Components:** The inner ring assembly (cone) and outer ring (cup) can be mounted separately.
  • Adjustable Clearance:** The axial clearance can be adjusted during mounting.
  • Robust Construction:** Capable of withstanding significant forces.
  • Versatile Application:** This bearing is known to be used in equipment from CLAAS, DANA SPICER, and MASSEY FERGUSON and is also known as T4CB 100. Typically used in pairs.
  • Manufacturing Origin:** Made in China.

Data sheet

Inner Diameter
100
Outer Diameter
145
Width
24
Roller Rows
Single Row
Cage
Steel Cage
Category
Single Row Tapered Roller Bearing
