81214 M RICH 70x105x27

81214.M RICH – Axial Cylindrical Roller Bearing – 70 x 105 x 27 mm

Technical Specifications:

• Type: Axial cylindrical roller bearing
• Brand: RICH
• Model Designation: 81214.M
• Inner Diameter (d): 70 mm
• Outer Diameter (D): 105 mm
• Total Height (H): 27 mm
• Cage Material: Machined brass (Rolling element guided)
• Weight: 0.863 kg
• Country of Origin: China

Performance Characteristics:

• Structural Configuration: Axial thrust bearing assembly comprising a cylindrical roller and cage set, a shaft washer, and a housing washer.
• Cage Specification: Features a high-strength machined brass cage (M) guided by the rolling elements, optimized for stability under heavy axial loads.
• Load Management: Designed to support unidirectional heavy axial forces with high mechanical stiffness and minimal axial deflection.
• Mechanical Interface: 70 x 105 x 27 mm dimensional format produced to standardized industrial tolerances for industrial and automotive drivetrain applications.

Transparency Note: This bearing is manufactured under the RICH brand. Any OE or interchangeable references are used solely for identification and do not imply affiliation with other manufacturers.
