5206 2RS RICH 30x62x23,8 52062RS RICH
search
  • 5206 2RS RICH 30x62x23,8 52062RS RICH

5206 2RS RICH 30x62x23,8

Type: Double Row Angular Contact Ball Bearing
Model: 5206.2RS RICH
Dimensions: 30 x 62 x 23.8 mm
Features: Sealed (2RS), Steel Cage
Brand: RICH
Origin: China
RICH
52062RS
€4.03
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

5206 2RS RICH Double Row Angular Contact Ball Bearing - 30 x 62 x 23.8 mm


Technical Specifications:

  • Catalog Code: 5206.2RS RICH
  • Brand: RICH
  • Type: Double row angular contact ball bearing
  • Bore Diameter (d): 30 mm
  • Outer Diameter (D): 62 mm
  • Width (B): 23.8 mm
  • Cage: Steel
  • Sealing: Double-sided rubber contact seal (2RS)
  • Clearance: CN (Normal internal clearance)
  • Weight: 0.3 kg
  • Country of Origin: China

Key Performance Advantages:

  • Bi-Directional Load Support: The dual-row angular contact design allows the 5206.2RS RICH to handle high radial loads and substantial axial loads from both directions, providing superior stability for rotating shafts.
  • Integrated Rubber Seals (2RS): The high-quality contact seals effectively keep lubricants inside while preventing the ingress of dust, water, and grit. This is crucial for maintaining the bearing's lifespan in harsh working environments.
  • Space-Saving Design: By combining two rows of balls into a single inner and outer ring, this bearing provides high rigidity and load capacity within a compact width of 23.8 mm, ideal for modern engineering applications.
  • High Tilting Rigidity: The back-to-back contact angle arrangement offers high resistance to tilting moments, ensuring precise movement and minimal vibration in pumps, gearboxes, and wheel hubs.
  • Durable Steel Cage: The steel cage is designed for strength and heat resistance, maintaining consistent ball spacing and smooth rotation even under heavy duty cycles.

Transparency Note: This product is manufactured under the RICH brand. The code 5206.2RS is used for identification purposes.

Data sheet

Inner Diameter
30
Outer Diameter
62
Width
23,8
Ball Rows
Double Row
Sealing
Lip Seal On Both Sides
Cage
Steel
Clearance
CN (Normal)
Category
Double Row Angular-Contact Ball Bearing
