LR5308-2RS RICH 40x100x36,5 LR53082RS RICH
zoom_out_map
LR5308-2RS RICH 40x100x36,5 LR53082RS RICH

LR5308-2RS RICH 40x100x36,5

RICH
LR53082RS
€12.22
No tax
Quantity
🏠 The Product Is In Our Warehouse And Will Arrive At Your Shipping Address Within 7–10 Business Days.

LR5308-2RS RICH Track Roller - 40 x 100 x 36.5 mm with Rounded Outer Ring

The LR5308-2RS RICH is a robust track roller engineered for linear motion systems and cam follower applications requiring high load capacity. It features a rounded outer ring to minimize stress on mating surfaces and double-sided rubber contact seals (2RS) for effective protection against contamination and reliable lubricant retention. Key dimensions are 40 mm inner diameter, 100 mm outer diameter, and 36.5 mm width. This track roller weighs 1.429 kg and is made in China.

Key Specifications:

  • Type: Track Roller
  • Dimensions:** 40 mm inner diameter x 100 mm outer diameter x 36.5 mm width
  • Weight:** 1.429 kg
  • Seals:** Double-sided rubber, contact (2RS)
  • Rounded Outer Ring:** Yes
  • Country of Origin:** China

Key Advantages:

  • Rounded outer ring designed to reduce stress and wear on guide rails.
  • Effective sealing (2RS) to protect against dust and debris.
  • Versatile use in linear motion and cam follower systems.
  • High load capacity for demanding applications.
  • Robust construction for reliable performance and long service life.
  • Smooth and precise movement.

Data sheet

Inner Diameter
40
Outer Diameter
100
Width
36,5
Sealing
Lip Seal On Both Sides
