F-569171.01 RICH 65x96x26
F-569171.01 RICH Double Row Angular-Contact Ball Bearing – dimensions 65 x 96 x 26 mm, weight 0.55 kg. Polyamide cage, inner split ring, open type (no seals). Ensures combined load support, smooth operation, and long service life.
F-569171.01 RICH | Double Row Angular-Contact Ball Bearing – 65 x 96 x 26 mm
Technical Specifications:
- Catalog Code: F-569171.01 RICH
- Brand: RICH
- Bearing Type: Double Row Angular-Contact Ball Bearing
- Inner Diameter (d): 65 mm
- Outer Diameter (D): 96 mm
- Total Width (T): 26 mm
- Outer Ring Width (C): 25 mm
- Weight: 0.55 kg
- Cage: Polyamide
- Sealing: None (open type)
- Split Ring: Inner
Key Performance Advantages:
- Double Row Angular-Contact Design: Supports combined radial and axial loads in both directions.
- Polyamide Cage: Lightweight, low-friction guidance of rolling elements for smooth operation.
- Inner Split Ring: Facilitates assembly and secure positioning.
- Optimized Dimensions: 65 mm bore, 96 mm outer diameter, 26 mm width.
- Open Type: Suitable for applications with external lubrication.
- RICH Quality: Precision manufactured for durability and consistent performance.
Transparency Note: This double row angular-contact ball bearing is manufactured directly under the RICH brand. The catalog code F-569171.01 is used solely for identification and does not imply affiliation with other brands. The product is clearly marked with its actual brand.
Data sheet
Inner Diameter
65
Outer Diameter
96
Width
26
Weight
0,55
Cage
Polyamide Cage
Category
Double Row Angular-Contact Ball Bearing
